HRE5000 SPECS

With capability to reach a 20’ tall pile

• MAST LENGTH 6200 MM ~ 20.34 FEET

• MAX RAMMING PILE WITH CUSTOM SLED 5000 MM ~ ((20 FEET))

• WEIGHT WITH IM 405 4800 KG ~ 10,582 LBS

• TRANSPORT DIMENSIONS

• Length 6200 MM ~ 20.34 FEET

• Base width 2200 MM ~ 7.21 FEET

• Height 2500 MM ~ 8.20 FEET

• IM 405 HAMMER BPM 530-1050

• IM 405 HAMMER JOULES PER HIT 1100 JOULES

• LIQUID COOLED ENGINE 3H50TICD SILENT PACK HATZ DIESEL

• ENGINE OUTPUT 2800 1/MIN / 42,0KW / 12V

• DECIBALS/VERTICAL MAX 117 DB / 20 DEGREES

HRE4000 SPECS

With capability to reach a 16’ tall pile

• MAST LENGTH 4700 MM ~ 15.41 FEET

• MAX RAMMING PILE W/OUT MAST EXTENSION 4200 MM ~ 13.77 FEET

• MAX RAMMING PILE WITH CUSTOM MAST SLED 4572MM ~ ((16 FEET))

• WEIGHT WITH IM 405 3700 KG ~ 8,157 LBS

• IM 405 HAMMER BPM 530-1050

• IM 405 JOULES PER HIT 1100 JOULES

• LIQUID COOLED ENGINE 3H50TICD SILENT PACK HATZ DIESEL

• ENGINE OUTPUT 2800 1/MIN / 42,0KW / 12V

• DB:/VERTICAL MAX 117 DB / 20 DEGREES
